Victron Orion IP20 24/12-80 DC-DC Converter

The Victron Orion 24/12-80 DC-DC Converter is a high-power, non-isolated converter designed to convert power from a 24V electrical system to a stable 12V output. Delivering up to 80A of continuous output current and 90A maximum output current, it is suitable for demanding vehicle, marine, and auxiliary power installations that require reliable voltage conversion.

Key Features

• Converts a 24V DC supply to an adjustable 12V DC output
• 18–35V DC input voltage range
• Adjustable output voltage from 10V to 15V
• Factory-set output voltage of 13.2V
• 80A continuous output current
• 90A maximum output current
• Up to 92% efficiency
• Suitable for buffer-charging a battery
• Can be connected in parallel to increase output current
• Up to five compatible units can be connected in parallel
• Temperature-controlled fan-assisted cooling
• Remote on/off connection
• M6 bolt power connections
• Non-isolated design

High-Power 24V to 12V Conversion

The Orion 24/12-80 provides dependable voltage conversion for installations where 12V equipment must be powered from a 24V electrical system. Its adjustable 10–15V output allows the converter to be configured for different 12V loads and battery-charging requirements.

With 80A of continuous output and a maximum output current of 90A, this converter is designed for high-current applications that require stable and efficient DC power.

Battery-Charging Capability

Because the output voltage is adjustable, the Orion 24/12-80 can also be used as a battery charger. For example, it can charge a 12V starter or accessory battery within an otherwise 24V electrical system.

Expandable Parallel Operation

Multiple Orion 24/12-80 converters can be connected in parallel to increase the total available output current. Victron specifies that up to five compatible units can be connected in parallel, providing flexibility for larger power requirements.

Remote On/Off Control

The integrated remote on/off connection eliminates the need for a high-current switch in the input wiring. It can be controlled using a low-power switch or an engine run/stop switch, depending on the installation.

Technical Specifications

• Brand: Victron Energy
• Model: Orion 24/12-80
• SKU: ORI241280020
• Product Type: High-Power DC-DC Converter
• Converter Type: Non-Isolated
• Input Voltage Range: 18–35V DC
• Undervoltage Shutdown: 14V
• Undervoltage Restart: 18V
• Output Voltage Range: Adjustable from 10–15V DC
• Factory-Set Output Voltage: 13.2V
• Continuous Output Current: 80A
• Maximum Output Current: 90A
• Efficiency: 92%
• Off-Load Current: Less than 20mA
• Cooling: Temperature-controlled fan-assisted cooling
• Remote On/Off: Yes
• Parallel Operation: Yes, up to five compatible units
• Operating Temperature: -20°C to +55°C
• Temperature Derating: 3% per °C above 40°C
• DC Connection: M6 bolts
• Dimensions: 65 × 88 × 195 mm (2.6 × 3.5 × 7.7 in)
• Weight: 0.9 kg (2.0 lb)

Ideal Applications

• 24V vehicles requiring a 12V power supply
• Marine electrical systems
• Commercial and service vehicles
• 12V starter or accessory battery charging in a 24V system
• High-current auxiliary equipment
• Dual-voltage DC electrical systems

Important: This is a non-isolated DC-DC converter. Confirm that a common negative connection is appropriate for the electrical system before installation.
