Orion IP67 12/24-50A (1200W) DC-DC Converter

The Orion IP67 12/24-50A (1200W) DC-DC Converter from Victron Energy is a heavy-duty, non-isolated voltage converter designed to efficiently convert 12V DC to a stable 24V DC output. Built for demanding environments, it features a fully encapsulated IP67-rated design that is waterproof, shockproof, and ignition protected, making it ideal for commercial vehicles, marine applications, industrial equipment, and off-grid power systems.

KEY FEATURES

Fully encapsulated IP67 housing for maximum protection against water, dust, oil, and dirt.
Cast aluminum enclosure with resin-moulded electronics for exceptional durability.
Wide 15–40V input voltage range for stable output during voltage fluctuations.
Extra-long 1.8 m (5.9 ft) input and output cables simplify installation.
High efficiency design for reliable power conversion.

SAFETY & PROTECTION

Waterproof, shockproof, and ignition protected (IP67).
Protected against overheating for reliable operation in high-temperature environments.
Suitable for use in engine compartments and other harsh operating conditions.
Designed for continuous-duty industrial and commercial applications.

COMPATIBILITY & INSTALLATION

Converts 12V DC systems to regulated 24V DC output.
Ideal for powering 24V equipment from a 12V battery system.
Perfect for commercial trucks, marine vessels, emergency vehicles, agricultural equipment, and off-grid installations.
Factory-installed 1.8 m (5.9 ft) cables reduce the need for additional wiring connections.

TECHNICAL SPECIFICATIONS

Input Voltage Range: 15–40V DC
Nominal Input Voltage: 12V DC
Nominal Output Voltage: 24V DC
Continuous Output Current: 50A
Continuous Output Power: 1200W
Efficiency: Up to 96%
Protection Rating: IP67
Operating Temperature: Suitable for high-temperature environments with thermal protection.
Input & Output Cables: 1.8 m (5.9 ft) pre-installed
Converter Type: Non-Isolated DC-DC Converter
Victron Energy SKU: ORI122421226
Warranty: 5 Years

APPLICATIONS

Commercial Trucks and Fleet Vehicles
Marine and Boat Electrical Systems
Emergency and Service Vehicles
Agricultural and Construction Equipment
Industrial Machinery
Off-Grid Power Systems

Documents:

GET THE VICTRON PEACE OF MIND

Energy. Anytime. Anywhere. With a 5 Year Warranty.

Monitoring, configuration and control

Battery Monitoring Made Easy with VictronConnect app

Victron Product Features

• Solar charger
• Battery charger
• Battery status
• Battery protection
• Battery monitoring via local display and via the VictronConnect app

Monitor Performance

Bluetooth Connectivity

Remotely control and monitor the extensive features of your SmartSolar MPPT charger with built-in Bluetooth by pairing it with your smartphone or other device via VictronConnect. If your installation is connected to the internet with a GX device, the Victron Remote Management Portal (VRM) provides access to the full power of your MPPT, anytime, anywhere; both VictronConnect and VRM are free to use. For remote installations - even when there is no internet connection nearby - you may be able to monitor your MPPT by connecting the GlobalLink 520.

GET THE VICTRON PEACE OF MIND

Energy. Anytime. Anywhere. With a 5 Year Warranty.

Victron Orion IP67 12/24-50A (1200W) DC-DC Converter FAQ

The Orion IP67 12/24-50A converts a 12V DC input into a regulated 24V DC output, providing stable power for 24V equipment from a 12V battery system. It is designed for demanding automotive, marine, industrial, and off-grid applications.

No. The Orion IP67 12/24-50A is a non-isolated DC-DC voltage converter. It is designed to provide regulated 24V DC power and is not intended as a multi-stage battery charger.

IP67 means the converter is completely protected against dust ingress and can withstand temporary immersion in water. The electronics are fully encapsulated in resin inside a cast aluminum housing for maximum durability.

Yes. The Orion IP67 is fully encapsulated, making it waterproof, shockproof, and ignition protected. Water, oil, dirt, and vibration will not damage the converter, making it ideal for harsh environments.

The ORI122421226 accepts an input voltage from 10V to 15V DC while maintaining a stable regulated 24V output.

This model provides a regulated 24V DC output (±3%), delivers up to 50A continuous output current, and supplies up to 1200W of continuous power with up to 96% efficiency.

Yes. The Orion IP67 features built-in thermal protection and can operate in environments up to +70°C, delivering full rated output up to +40°C before automatic derating begins.

Yes. The converter includes automatic hiccup-mode overload protection, short-circuit protection, and requires an external fuse or circuit breaker for reverse-polarity protection.

The factory-installed 1.8 m (5.9 ft) input and output cables reduce the need for additional cable connections, improving reliability while maintaining the IP67 waterproof rating.

The Orion IP67 12/24-50A measures 265 × 127 × 63 mm (10.4 × 5.0 × 2.5 inches) and weighs approximately 2.15 kg (4.74 lb).

This converter is ideal for commercial trucks, buses, emergency vehicles, marine vessels, agricultural machinery, construction equipment, industrial systems, and off-grid power applications that require reliable 24V power from a 12V battery source.

Key features include a fully encapsulated IP67 design, cast aluminum housing, resin-moulded electronics, wide input voltage range, up to 96% efficiency, thermal protection, waterproof construction, ignition protection, and shockproof operation.
